Keysight Technologies InfiniiVision 6000 X Series

Testing Performance 2
6000 X-Series Oscilloscopes Service Guide 47
3 Connect the equipment (see Figure 8).
a Connect the signal generator output to the oscilloscope channel 1 input.
Figure 8 Setting Up Equipment for Internal Trigger Sensitivity Test
b Set channel 1 Impedance to 50 Ohm.
Signal
Generator
Oscilloscope
N Cable
N to BNC Adapter
