52 6000 X-Series Oscilloscopes Service Guide
2 Testing Performance
Keysight 6000 X-Series Oscilloscopes Performance Test Record
Serial No. ______________________________________ Test by _____________________________
Test Interval ____________________________________ Work Order No. ______________________
Recommended Next Testing ________________________ Temperature ____________
Threshold Specification Limits Ch D7-D0 Ch D15-D8
Accuracy Test 5 V - 250 mV 4.750 V ________ ________
(100 mV + 3% of
threshold setting)
5 V + 250 mV 5.250 V ________ ________
-5 V - 250 mV -5.250 V ________ ________
-5 V + 250 mV -4.750 V ________ ________
0 V - 100 mV -100 mV ________ ________
0 V + 100 mV 100 mV ________ ________
DC Vertical Gain Accuracy
Range Power Supply Setting Test Limits Channel 1 Channel 2 Channel 3* Channel 4*
5 V/Div 35 V 34 V to 36 V ________ ________ ________ ________
2 V/Div 14 V 13.6 V to 14.4 V ________ ________ ________ ________
1 V/Div 7 V 6.8 V to 7.2 V ________ ________ ________ ________
500 mV/Div 3.5 V 3.4 V to 3.6 V ________ ________ ________ ________
200 mV/Div 1.4 V 1.36 V to 1.44 V ________ ________ ________ ________
100 mV/Div 700 mV 680 mV to 720 mV ________ ________ ________ ________
50 mV/Div 350 mV 340 mV to 360 mV ________ ________ ________ ________
20 mV/Div 140 mV 136 mV to 144 mV ________ ________ ________ ________
10 mV/Div 70 mV 68 mV to 72 mV ________ ________ ________ ________
5 mV/Div 35 mV 34 mV to 36 mV ________ ________ ________ ________
2 mV/Div 14 mV 13.6 mV to 14.4 mV ________ ________ ________ ________
1 mV/Div 7 mV 6.6 mV to 7.4 mV ________ ________ ________ ________
Continued on next page.
