Testing Performance 2
6000 X-Series Oscilloscopes Service Guide 53
Dual Cursor Accuracy
Range Power Supply Setting Test Limits Channel 1 Channel 2 Channel 3* Channel 4*
5 V/Div 35 V 33.832 V to 36.168 V ________ ________ ________ ________
2 V/Div 14 V 13.533 V to 14.467 V ________ ________ ________ ________
1 V/Div 7 V 6.766 V to 7.234 V ________ ________ ________ ________
500 mV/Div 3.5 V 3.383 V to 3.617 V ________ ________ ________ ________
200 mV/Div 1.4 V 1.353 V to 1.447 V ________ ________ ________ ________
100 mV/Div 700 mV 676.64 mV to 723.36 mV ________ ________ ________ ________
50 mV/Div 350 mV 338.32 mV to 361.68 mV ________ ________ ________ ________
20 mV/Div 140 mV 135.33 mV to 144.67 mV ________ ________ ________ ________
10 mV/Div 70 mV 67.66 mV to 72.34 mV ________ ________ ________ ________
5 mV/Div 35 mV 33.83 mV to 36.17 mV ________ ________ ________ ________
2 mV/Div 14 mV 13.53 mV to 14.47 mV ________ ________ ________ ________
1 mV/Div 7 mV 6.533 mV to 7.467 mV ________ ________ ________ ________
Bandwidth (-3 dB) Model BW Option Test Limits Channel 1 Channel 2 Channel 3* Channel 4*
BW600 -3 dB at 6 GHz ________ ________ ________ ________
BW400 -3 dB at 4 GHz ________ ________ ________ ________
BW250 -3 dB at 2.5 GHz ________ ________ ________ ________
(none) -3 dB at 1 GHz ________ ________ ________ ________
Time Base Accuracy Limits Measured
time base
error (ppm)
Pass/Fail
Time Base Accuracy Limit: ±1.6 ppm + aging
________ ________
Continued on next page.
