30 6000 X-Series Oscilloscopes Service Guide
2 Testing Performance
2 Set up the oscilloscope.
a Adjust the horizontal scale to 200.0 us/div.
b Set the Volts/Div setting to the value in the first line in Table 8 (depending
on the oscilloscope model).
c Adjust the channel’s vertical position knob to place the baseline (reference
level) at 0.5 major division from the bottom of the display.
d Press the [Acquire] key.
e Then press the Acq Mode softkey and select Averaging.
f Then press the #Avgs softkey and set it to 64.
Wait a few seconds for the measurement to settle.
Table 8 Settings Used to Verify DC Vertical Gain Accuracy
Volts/Div Setting Precision Source Setting Test Limits
5V/Div 35V 34V to 36V
2 V/Div 14 V 13.6 V to 14.4 V
1V/Div 7V 6.8V to 7.2V
500 mV/Div 3.5 V 3.4 V to 3.6 V
200 mV/Div 1.4 V 1.36 V to 1.44 V
100 mV/Div 700 mV 680 mV to 720 mV
50 mV/Div 350 mV 340 mV to 360 mV
20 mV/Div 140 mV 136 mV to 144 mV
10 mV/Div 70 mV 68 mV to 72 mV
5mV/Div
1
35 mV 34 mV to 36 mV
2mV/Div
1, 2
14 mV 13.6 mV to 14.4 mV
1mV/Div
1, 2
7mV 6.6mV to 7.4mV
1
A blocking capacitor is required at this range to reduce noise. See “Use a Blocking Capacitor to
Reduce Noise" on page 33.
2
Full scale is defined as 16 mV on the 1 mV/div range. Full scale on all other ranges is defined as 8
divisions times the V/div setting.
