List of Test Equipment
Below is a list of test equipment and accessories required to perform the
performance test verification procedures.
Table 1 List of test equipment
Equipment Critical Specifications Recommended Model/ Part Number
Test connector, 8-by-2* See page 21 for instructions on building test
connector.
n/a
Digital Multimeter 0.1 mV resolution, 0.005% accuracy Keysight 34401A/34461A
Power Splitter Outputs differ by 0.20 dB Keysight 11667A
Precision Source DC voltage of -5.5 V to 35.5 V, 0.1 mV resolution Keysight B2912A/B2962A
Signal Generator 100 kHz to 6 GHz sine waves Keysight N5171B with 6 GHz option
Power Meter 6 GHz
±3% accuracy Keysight N1914A
Power Sensor 6 GHz ±3% accuracy Keysight E9304A or N8482A
50
Ω BNC Cable (qty 3) BNC - BNC, 48” length Keysight 8120-1840
†
Cable Type N (m) 609.6 mm (24 in.) Keysight 11500B
Probe cable* No substitute 16-chanel: Keysight N6450-60001 or
N2756-60001
8-channel: Keysight N6459-60001 or
N2755-60001
†
Adapter (qty 2) BNC (f) to banana (m) Keysight 1251-2277
†
BNC Tee BNC Tee (m) (f) (f) Keysight 1250-0781
†
or Pomona 3285
Adapter Type N (m) to BNC (m) Keysight 1250-0082 or
Pomona 3288 with Pomona 3533
Shorting cap BNC Keysight 1250-0774
Blocking capacitor Note: if a BNC blocking capacitor is not available use
an SMA blocking capacitor.
Keysight 11742A +
Pomona 4289 +
Pomona 5088
50 Ohm Feedthrough
Termination
50Ω BNC (f) to BNC (m) Keysight 0960-0301
* Required only for testing digital channels of oscilloscopes that have the MSO option.
Most parts and equipment are available at www.keysight.com. See respective manufacturer’s websites for their equipment.
†
These parts available at www.parts.keysight.com at the time this manual was published.
