54 6000 X-Series Oscilloscopes Service Guide
2 Testing Performance
Internal Trigger Sensitivity
Generator Setting Test Limits Channel 1 Channel 2 Channel 3* Channel 4*
6GHzmodels,
4GHzmodels,
2.5 GHz models:
3.5 GHz < 10 mV/div: greater of
1.5 div or 5 mVpp
________ ________ ________ _______
>= 10 mV/div: 1 div ________ ________ ________ _______
2 GHz < 10 mV/div: greater of 1 div
or 5 mVpp
________ ________ ________ _______
>= 10 mV/div: 0.6 div ________ ________ ________ _______
1 GHz models: 1 GHz < 10 mV/div: greater of 1 div
or 5 mVpp
________ ________ ________ _______
>= 10 mV/div: 0.6 div ________ ________ ________ _______
External Trigger Sensitivity
Input Range: 8 V Generator Setting Test Limits Ext Trig In
200 MHz 350 mV ________
100 MHz 200 mV ________
Input Range: 1.6 V Generator Setting Test Limits Ext Trig In
200 MHz 70 mV ________
100 MHz 40 mV ________
* Where applicable
