122 6000 X-Series Oscilloscopes Service Guide
6 Replaceable Parts
MP8 54609-41901 1 Keyboard Keypad
MP9 54709-41903 1 Softkey Keypad
MP10 54609-44102 1 Cover Protective Front
MP11 54609-00101 1 Front Deck
MP12 54609-00102 1 Rear Deck
MP13 54609-00602 1 Shield Power Supply
MP14 54609-00604 1 Shield AC Input
MP15 54609-00606 1 Shield Probe Power
MP16 54609-44701 1 Fan Mount
MP17 3160-4377 1 Fan
MP18 54695-43901 1 Extender, Power Switch
MP19 54609-64401 1 Cabinet Assembly
Not shown 54609-87101 1 Chassis to Fan Seal
MP20 54609-61606 1 Speaker Assembly
Table 23 Replaceable Parts (continued)
Ref Des Keysight Part
Number
Qty Description
To Next Page
