4 Changing the Default Settings
140 Keysight U1253B User’s and Service Guide
As another example, Figure 4-28 below illustrates that:
– The F6 default function is changed from capacitance measurement to
temperature measurement;
– The F7 default measurement range for DC μA is changed from Auto to 5000 μA;
– The F8 default measurement range for DC mA is changed from Auto to 50 mA;
– The F8A default measurement range for DC A is changed from Auto to 5 A;
– The F9 default output values for pulse width and duty cycle are both changed
from the 128th step (0.8333 ms for pulse width and 50.000% for duty cycle) to
the 255th step (1.6601 ms for pulse width and 99.609%).
Figure 4-28 Editing initial measurement function/range and initial output
values
After making the desired changes, press to save the changes. Press
exit the EDIT mode.
If you reset the multimeter to its default factory settings (see “Returning to default
factory settings” on page 142), your settings for M-INITIAL will also revert to the
factory defaults.
Edit initial functions
and ranges
