Keysight Technologies U1253B - The Keypad at a Glance; Figure 1-7 U1253 B Keypad

1 Getting Started
32 Keysight U1253B User’s and Service Guide
The keypad at a glance
The operation of each key is explained in Table 1-2 below. Pressing a key displays
a related symbol and emits a sound on the beeper. Turning the rotary switch to
another position resets the current operation of the key. Figure 1-7 shows the
keypad of the U1253B.
Figure 1-7 U1253B keypad
4
3
2
1
5
6
7
