Making Measurements 2
Keysight U1253B User’s and Service Guide 69
Figure 2-10 Short continuity and open continuity test
Conductance
Set up the multimeter to measure conductance as shown in Figure 2-11. Probe
the test points and read the display.
The conductance measurement function makes it easier to measure very high
resistance of up to 100 GΩ. As high-resistance readings are susceptible to noise,
you can capture average readings using the Dynamic Recording mode. Refer to
the section “Dynamic Recording” on page 84 for more information.
Short continuity
Open continuity
Press
Press
