Making Measurements 2
Keysight U1253B User’s and Service Guide 65
The Smart Ω is applicable for 500 Ω, 5 kΩ, 50 kΩ, and 500 kΩ resistance range
only. The maximum correctable offset/bias voltage is ±1.9 V for 500 Ω range and
±0.35 V for 5 kΩ, 50 kΩ, and 500 kΩ range.
– Press to enable Smart Ω feature. Press again to cycle through
Bias display or Leak display.
– Press for more than one second to disable Smart Ω feature.
Figure 2-7 Type of display when Smart Ω is enabled
The measurement time increases when Smart Ω is enabled.
Bias display
Leak display
Press
Press
