2 Making Measurements
68 Keysight U1253B User’s and Service Guide
Audible continuity
In the range of 500 Ω range, the beeper will emit a sound if the resistance value
falls below 10 Ω. For other ranges, the beeper will emit a sound if the resistance
falls below the typical values listed in Table 2-3 below.
Table 2-3 Audible continuity measurement range
Measurement range Beeper sound threshold
500.00 Ω < 10 Ω
5.0000 kΩ < 100 Ω
50.000 kΩ < 1 kΩ
500.00 kΩ < 10 kΩ
5.0000 MΩ < 100 kΩ
50.000 MΩ < 1 MΩ
500.00 MΩ < 10 MΩ
When testing continuity, you can choose to test either short continuity or open
continuity.
– By default, the multimeter is set to short continuity.
– Press to select open continuity.
