A (ampere) measurement
Set up the multimeter to measure A (ampere) as shown in Figure 2-5. Probe the
test points and read the display.
Figure 2-5 A (ampere) current measurement
Connect the red and black test leads to 10 A input terminals A (red) and COM
(black) respectively. The multimeter is set to measurement automatically
when the red test lead is plugged into the A (red) terminal.
