1 Getting Started
46 Keysight U1253B User’s and Service Guide
(Press twice to select AC+DC
current)
AC+DC A Hz (AC coupling)
AC+DC A AC A
AC+DC A DC A
(Capacitance)/ (Diode)/
(Conductance)
nF / V / nS
No secondary display. Ambient temperature in ºC
or ºF is displayed in upper-right corner.
(Resistance)
Ω
DC mV Bias, DC A Leak
Ambient temperature in ºC or ºF is displayed in
upper-right corner.
(Temperature)
ºC (ºF)
If ºC/ºF or ºF/ºC dual-display is selected in the
Setup, then the secondary display will indicate
the temperature in the other unit (as opposed to
the primary display). If single-unit display is
selected in the Setup, there will be no secondary
display. Ambient temperature in ºC or ºF is
displayed in upper-right corner. Select 0 ºC
compensation by pressing .
Notes for selecting display with DUAL button:
[a] Depends the relevant setting in Setup mode.
Table 1-8 Selecting display with the Dual button (continued)
Rotary switch position (Function) Primary display Secondary d isplay
