1 Getting Started
48 Keysight U1253B User’s and Service Guide
(Press twice to select AC+DC voltage)
Frequency (Hz)
AC+DC mVPulse width (ms)
Duty cycle (%)
(Default is DC current)
Frequency (Hz)
DC μAPulse width (ms)
Duty cycle (%)
(Press to select AC current)
Frequency (Hz)
AC μAPulse width (ms)
Duty cycle (%)
(Press twice to select AC+DC current)
Frequency (Hz)
AC+DC μAPulse width (ms)
Duty cycle (%)
(Default is DC current)
Frequency (Hz)
DC mA or APulse width (ms)
Duty cycle (%)
(Press to select AC current)
Frequency (Hz)
AC mA or APulse width (ms)
Duty cycle (%)
(Press twice to select AC+DC current)
Frequency (Hz)
AC+DC mAPulse width (ms)
Duty cycle (%)
Hz (Frequency counter)
(Only applicable for Divide-1 input)
Frequency (Hz) Pulse width (ms)
Pulse width (ms)
Frequency (Hz)
Duty cycle (%)
Table 1-9 Selecting display with the Hz button (continued)
Rotary switch position (Function) Primary display Secondary display
