Glitch or Narrow Pulse Capture
A glitch is a rapid change in the waveform that is usually narrow as compared to
the waveform. Peak detect mode can be used to more easily view glitches or
narrow pulses. In peak detect mode, narrow glitches and sharp edges are
displayed more brightly than when in Normal acquire mode, making them easier
to see.
To characterize the glitch, use the cursors or the automatic measurement
capabilities of the oscilloscope.
Figure 37 Sine With Glitch, Normal Mode
