42 Keysight InfiniiVision 3000T X-Series Oscilloscopes User's Guide
1 Getting Started
13. File keys Press the [Save/Recall] key to save or recall a waveform or setup. See Chapter 20,
“Save/Email/Recall (Setups, Screens, Data),” starting on page 321.
The [Print] key opens the Print Configuration Menu so you can print the displayed waveforms.
See Chapter 21, “Print (Screens),” starting on page 335.
14. Tools keys The Tools keys consist of:
• [Utility] key — Press this key to access the Utility Menu, which lets you configure the
oscilloscope's I/O settings, use the file explorer, set preferences, access the service menu,
and choose other options. See Chapter 22, “Utility Settings,” starting on page 341.
• [Quick Action] key — Press this key to perform the selected quick action: measure all
snapshot, print, save, recall, freeze display, and more. See “Configuring the [Quick
Action] Key" on page 357.
•[Wave Gen] key — Press this key to access waveform generator functions. See
Chapter 19, “Waveform Generator,” starting on page 301.
•[Analyze] key — Press this key to access analysis features like:
• Measurement threshold setting.
• Trigger level setting.
• Video trigger automatic set up and display.
• Counter (DVMCTR) (see “Counter" on page 291).
• Digital voltmeter (DVMCTR) (see “Digital Voltmeter" on page 290).
• Mask testing (see Chapter 16, “Mask Testing,” starting on page 275).
• The DSOX3PWR power measurement and analysis application.
15. [Help] key Opens the Help Menu where you can display overview help topics and select the Language.
See also “Access the Built-In Quick Help" on page 61.
16. Vertical controls The Vertical controls consist of:
• Analog channel on/off keys — Use these keys to switch a channel on or off, or to access a
channel's menu in the softkeys. There is one channel on/off key for each analog channel.
• Vertical scale knob — There are knobs marked for each channel. Use these knobs
to change the vertical sensitivity (gain) of each analog channel.
• Vertical position knobs — Use these knobs to change a channel's vertical position on the
display. There is one Vertical Position control for each analog channel.
For more information, see Chapter 3, “Vertical Controls,” starting on page 79.
