Reference 24
Keysight InfiniiVision 3000T X-Series Oscilloscopes User's Guide 385
Example Program for Reading Binary Data
To find an example program for reading binary data, direct your web browser to
www.keysight.com/find/3000TX-Series-examples, and select "Example Program
for Reading Binary Data".
Examples of Binary Files
Single Acquisition
Multiple Analog
Channels
The following picture shows a binary file of a single acquisition with multiple
analog channels.
Buffer Type A 16-bit short that is the type of waveform data stored in the file:
• 0 = Unknown data.
• 1 = Normal 32-bit float data.
• 2 = Maximum float data.
• 3 = Minimum float data.
• 4 = Not used in InfiniiVision oscilloscopes.
• 5 = Not used in InfiniiVision oscilloscopes.
• 6 = Digital unsigned 8-bit char data (for digital channels).
Bytes Per Point A 16-bit short that is the number of bytes per data point.
Buffer Size A 32-bit integer that is the size of the buffer required to hold the data points.
