Horizontal Controls 2
Keysight InfiniiVision 3000T X-Series Oscilloscopes User's Guide 75
• Press Copy from Trigger to copy the trigger setup for the selected search type
to the search setup.
• To undo a copy, press Undo Copy.
The softkeys in the Search Copy Menu may not be available when one of the
settings cannot be copied or there is no trigger type that corresponds to the
search type.
Navigating the Time Base
You can use the [Navigate] key and controls to navigate through:
• Captured data (see “To navigate time" on page 75).
• Search events (see “To navigate search events" on page 75).
• Segments, when segmented memory acquisitions are turned on (see “To
navigate segments" on page 76).
You can also access navigation controls on the touchscreen. See “Select Sidebar
Information or Controls" on page 49.
To navigate time
When acquisitions are stopped, you can use the navigation controls to play
through the captured data.
1 Press [Navigate].
2 In the Navigate Menu, press Navigate; then, select Time.
3 Press the navigation keys to play backward, stop, or play forward in
time. You can press the or keys multiple times to speed up the
playback. There are three speed levels.
You can also access navigation controls on the touchscreen. See “Select Sidebar
Information or Controls" on page 49.
To navigate search events
When acquisitions are stopped, you can use the navigation controls to go to found
search events (set using the [Search] key and menu, see “Searching for Events" on
page 73).
