Keysight E5092A ENA Series Configurable Multiport Test Set 85
Performance Tests
E5092A Performance Test Record
Load Match, Insertion Loss and Isolation Test for Switch 3 (SP4T, Port 3, 3A, 3B,
3C and 3D)
Load Match (Unselected)
Port
(Selected
Port)
Frequency
Range [Hz]
Test Limit
[dB]
Test Result [dB] Measurement
Uncertainty [dB]
3B (3A) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
3C (3A) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
3D (3A) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
3A (3B) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
3C (3B) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
