KGuard Security HD881 - Capture Schedule (Continued)

20
Hybrid DVR (HD Series)
• Sensor: When the me slot is marked white, capturing snapshots is determined by the camera type that is connected to the channel:
(1) PIR or Smoke Detector Camera: If the PIR camera detects a moon or the Smoke detector camera detects smoke, the channel captures snapshots during the me
slots that are marked white in the capture schedule.
NOTE: Make sure Main Menu > Parameter > Capture > Capture > Auto Capture is enabled for the channel.
(2) Camera that is linked to the PIR or Smoke Detector Camera: If the PIR or Smoke sensor is triggered, the channel of the camera that is linked to the PIR or Smoke
detector camera starts capturing screenshots during the me slots that are marked white in the capture schedule:
1. Channel: Open Main Menu > Parameter > Capture > Capture and select the channel you want to link to the PIR or Smoke detector camera.
2. Enable Auto Capture and save the sengs.
3. Channel: Open Main menu > Parameter > Alarm > Sensor Control and select the PIR camera.
4. Record Channel: Select the channel that you want to link to the PIR camera and save the sengs.
5. Repeat steps 3 and 4 for the Smoke detector camera.
6. Set PIR-based recording for the camera that is now linked to the PIR and Smoke detector cameras: Open Main Menu > Parameter > Record > Record Schedule and
set the schedule for PIR recording.
NOTE: For PIR, Siren, and Smoke detector camera product informaon, please visit the KGUARD ocial webpage at hp://www.kguardsecurity.com/ and search for the
following model names:
- “WP820A“ for PIR camera
- “WR820A“ for Siren camera
- “WS820A“ for Smoke detector camera
• No Capturing: A me slot marked black means that there is no snapshot capturing scheduled for the me slot.
Main Menu > Parameter > Capture > Capture Schedule (connued)
