KidKraft Cedar Summit DEVONSHIRE ELITE - Attach Tower Roof

50
4 x #8 x 3” Wood Screw
Hardware
S4
x 2 per
side
S4
2853
9379
A: With a helper, lift the roof assembly and place it onto the tower assembly so that the (2853) Roof Supports
are ush to (9379) Softs. Attach (2853) Roof Supports to (9379) Softs using 2 (S4) #8 x 3” Wood Screws per
support. (g 17.1 and 17.2)
Step 17: Attach Tower Roof
Fig. 17.1
Fig. 17.2
