Step 48: TNR Brace Assembly
A: Attach (8965) TNR Upright to (8963) TNR Ground Brace with 1 (H4) 1/4 x 4” Hex Bolt (with lock washer, at
washer and t-nut) in the top hole. Make sure both boards are square then attach with 1 (S4) #8 x 3” Wood Screw.
(Fig. 48.1)
1 x #8 x 3” Wood Screw
1 x 1/4 x 4” Hex Bolt (LW1, FW1, TN1)
Hardware
Wood Parts
1 x TNR Ground Brace 1¼ x 3 x 32¼”
1 x TNR Upright 1¼ x 3 x 20¼”
H4
S4
8963
8965
Fig. 48.1
8963
H4
8965
S4
TN1
FW1
LW1
