KidKraft Cedar Summit DEVONSHIRE ELITE - Attach Telescope

83
Hardware
S11
2 x #8 x 2” Wood Screw
9377
9370
9376
Other Parts
1 x Telescope
Telescope Base
Telescope
S11
Fig. 38.1
Fig. 38.2
Step 38: Attach Telescope
A: Centered and ush to the edge of (9377) Window Brace pre-drill with a 1/8” drill bit and attach Telescope Base
to (9377) Window Brace with 2 (S11) #8 x 2” Wood Screws then slide Telescope into place. (Fig 38.1 & 38.2)
