Step 34: Canopy Frame Assembly
A: Feed Cafe Canopy Frame through the pocket of the Cafe Canopy. (g. 34.1 and 34.2)
B: Connect both sections of the café frame together using 2 (MB1) #12 x ½” Machine Bolts (with #12 lock nut).
(g. 34.3 and 34.4)
Other Parts
2 x Café Frame
Cafe
Frame
Fig. 34.1
Fig. 34.2
Fig. 34.3
Hardware
2 x #12 x 1/2” Machine Bolt (LN4)
MB1
Cafe Canopy
Frame
Fig. 34.4
Cafe
Canopy
MB1
MB1
LN4
LN4
