KidKraft Cedar Summit DEVONSHIRE ELITE - Tower Roof Support Assembly

45
x 4
H11
Hardware
2 x Soft 1 x 2 x 41-5/32”
Wood Parts
9379
4 x 1/4 x 2-3/4” Hex Bolt
(LW1, FW1, TN1)
H11
9460
9379
A: Place 1 (9379) Soft across each side of the (9460) Supports as shown in g. 14.1, making sure that they are
ush with the tops of the supports. Attach using 2 (H11) 1/4 x 2- 3/4” Hex Bolts (with lock washer, at washer and
t-nut) per side. (g 14.1)
Step 14: Tower Roof Support Assembly
Part 1
Fig. 14.1
TN1
FW1
LW1
