2 x Floor Joist 1¼ x 3 x 40¾”
Wood Parts Hardware
2608
8 x #12 x 2” Pan Screw
S7
x 4 per board
S7
Tight
2608
9372
9214
Fig. 7.1
Step 7: Join Swing and Slide Assemblies
Part 1
A: With at least one helper, bring the 2 assemblies together so the wall panels meet tightly. Panels should be ush
at the tops and bottom. (g. 7.1)
B: Place (2608) Floor Joist across the joints on each side, making sure that they are tight to the (9214) End Slide
Panel. Attach using 4 (S7) #12 x 2” Pan Screws per board. (g. 7.1)
9248
To Next Page
