KidKraft Cedar Summit DEVONSHIRE ELITE - Attach Access Ladder;Rockwall

60
A: Place Access Ladder/Rockwall Assembly against Back Wall Panel and ush to the top of the oor boards then
attach with 4 (S20) #8 x 1 -3/8” Wood Screws. (g. 22.1 and 22.2)
Hardware
Fig. 22.1
Step 22: Attach Access Ladder/Rockwall
Part 1
Fig. 22.2
9364
Flush
Floor Boards
2-1/8”
4 x #8 x 1-3/8” Wood Screw
S20
S20
Access Ladder/
Rockwall Assembly
