KidKraft Cedar Summit DEVONSHIRE ELITE - Table Top Assembly

31 31
Hardware
6 x # 8 x 7/8” Truss Head Screw
S0
Other Parts
2 x Flat Bracket
Table Top
Assembly
Flat
Bracket
S0
x 3 per
bracket
C: From the inside of the assembly attach (9324) Table Top to slats in Front Wall Panel with 2 Flat Brackets using
3 (S0) #8 x 7/8” Truss Head Screws per bracket. (g. 5.4)
Step 5: Table Top Assembly
Part 2
Fig. 5.4
9324
