Hardware
Wood Parts
4 x #12 x 2” Pan Screw
2 x #8 x 2-1/2” Wood Screw
S3
S7
S3
x 2
Table Top
Assembly
9324
2612
9361
9220
9375
1 x Table Top 15/16 x 4-1/4 x 42-25/32”
1 x Table Support 1-1/2 x 1-1/2 x 39-5/8”
9324
2612
A: Place (2612) Table Support ush to the notched out ends of (9324) Table Top and attach with 4 (S7) #12 x 2”
Pan Screws as shown in g. 5.1.
B: Place Table Top Assembly in the center of opening and tight to Front Wall Panel and attach (2612) Table
Support to Front Wall Panel with 2 (S3) #8 x 2-1/2” Wood Screws. (g. 5.2 and 5.3)
Step 5: Table Top Assembly
Part 1
Fig. 5.2
Fig. 5.3
Fig. 5.1
Flush
S7
1-1/2”
40mm
