KidKraft Cedar Summit DEVONSHIRE ELITE - Page 82

82
4 x 1/4 x 1-1/4” Hex Bolt (LW1, FW1, TN1)
H9
Hardware
Inside View
Stool
Assembly
H9
H9
9220
Fig. 37.3
Fig. 37.4
Step 37: Stool Seat Assembly
Part 2
C: Attach Stool Seat Assembly to Front Wall Panel using 4 (H9) ¼ x 1- ¼” Hex Bolts (with lock washer, at wash-
er and t-nut). (g. 37.3 & 37.4).
TN1
FW1
FW1
LW1
LW1
TN1
