Issue: 08/2012
Via pulses the main drive encoder counts quantity of lm (transport unit = 1 picture),
which is transported out of feed sprocket into lm gate.
If one “transport unit” is completely counted and shutter position is dark the motor of
intermittent sprocket carries on lm for one picture.
This operation is controlled by a microprocessor which is mounted on main board.
X
Z In this chapter you will get an overview of the electronic components, which are
mounted in the projector console.
Z The console door should only be opened by authorized service staff.
Z All work on electronic parts must be carried out only by experts.
Main board
Á FPS 300 amplier
 Power supply unit for FPS 300
à Mains transformer
Ä EMK 1 automation system
(option)
The is the projector’s control center. It provides:
» DIP switches for setting projector functions
» LEDs for, e. g. shutter adjustment indication or voltage error indication
» Interfaces for different connections.
2
3
5
1
4
