Issue: 06/2011

 
X 
Z The reector should only be changed by the projectionist in case of need.
At the next opportunity the reector should be adjusted nely by service personnel
who has the necessary alignment tool.
Z At normal case the reector should be changed and adjusted by service personnel.
Z The following chapter describes how the reector can be changed in case of need.
Xenon bulb
Á Reector
 Bulb support (only big lamphouses)
à Anode connecting bolt
Ä Adjusting/xing screws
Å Counterscrew
Handle star

Observe the safety instructions, when opening the lamphouse.
- Switch off the projector.
- Wear protective clothes.
- Open the lamphouse only after waiting period of at least 10 minutes.

Remove the lamphouse door.
Remove the xenon bulb.
Loosen the upper holder rod by turning the handle star .
Carefully take out the reector by tilting it forwards while the upper holder bar is
moved upwards.
At this opportunity clean lamphouse by blowing compressed air in the lamphouse and
nally remove the dust with a vacuum cleaner.
2
1
3
4
5
5
6
7
