Technical Data
Issue: 08/2012
Name Cinema Projector
Type FP 50 E PREMIERE
Machine No. See data plate on housing.
Power supply 120/208 V, 3 ph, 5 wire -OR-
230/380 V, 5 wire
Frequency 50 Hz / 60 Hz
Pre-fuse 10 A
Power max. Depends on equipment, see data plate
Nominal rotary frequency of
main motor
1500 rpm
Power of main drive motor 100 W
Framing Endless via remote control
Running speed 24/25 fps
Projector 1500 mm x 714 mm x 2240 mm approx. 300 kg
Film reels 600 m / 1800 m / 2000 m
Friction shafts Ø 9 mm or Ø 12.7 mm
Lens holder / turret for lenses Ø 70.6 mm
Apertures 1:1.37 / 1:1.66 / 1:2.35 (FP 30 E)
