Repair and Adjustments
Issue: 06/2011
The heat lter is a reection lter, therefore you have to watch out for the reection side
of lter to be directed to xenon lamp (marked with a black dot).
• Remove the old lter.
• Open the lamphouse.
• Put the heat lter onto the holders.
• Close the lamphouse.
• Remove the shutter housing.
• Put the heat lter into the slits of the
holders.
• Close the shutter housing.
