Issue: 08/2012
+ 24 V rd
- 24 V bl
Start FOR-
WARDS
wt K2 / 24 3 1
GND / com bk K2 / 1, 12, 13 19 1 + 2
Stop rs K2 / 25 35 2
Dowser OPEN ye K2 / 27 44 3
GND / com bk K2 / 1, 12, 13 43 3 + 4
Dowser CLOSE or K2 / 26 28 4
GND / com bk K2 / 1, 12, 13 23 5 + 6 +7
Lens turret NS gr K2 / 16 39 5
Lens turret WS or K2 / 15 7 6
Lens turret CS ye K2 / 14 8 7
Focusing - vio K2 / 17
GND / com bk K2 / 1, 12, 13
Focusing + rs K2 / 18
Framing DOWN wt/gn K2 /21
GND / com bk K2 / 1, 12, 13
Framing UP wt/bl K2 / 20
Sensor 1 wt Auto start with EMK
outboard sensor with
SA2 / CCA3
17 Input 1
Sensor 2 gn Sensor with EMK
inboard sensor with
SA2 / CCA3
Sensor 3 (with CCA 3, DMP 1) center sensor
Reverse (with CCA 3, DMP 1 or SA 2) K2-23
External start (with SA 2)
EMERGENCY (with CCA 3, DMP 1 or SA 2)
