Repair and Adjustments
Issue: 06/2011
S Xenon bulbs should only be changed by trained personnel.
S Xenon bulbs are high-pressure glow-discharge lamps in which a high interior
pressure exists even if not in operation.
S Inserting the xenon bulb wear safety cloves, face protection and protective suit.
Do not insert the xenon bulb with any violence.
S Do not insert the xenon bulb by touching it at the anode base.
S Install the xenon bulb only in its protective coat.
Reflector
Á Xenon bulb
 Anode (+) cable connection
à Bulb support
(only in big lamphouses)
• Remove the lamphouse door, by loosening the 2 Allen screws.
• Remove the anode cable from the lamphouse connecting bolt.
2
1
4
3
