» In the lm gate the lm is precisely positioned. With the lm pressure skate the pic-
ture steadiness can be optimized. The four ceramics rollers guide the lm laterally.
» The FP 75 E projector can operate with 35 mm lms and 70 mm lms, therefore
some components have to be changed with the lm format.
» The lm gate can be removed completely.
Combined feed sprocket
Á Film runner strips (2)
 Knurled screw to fasten the lm gate
à Combined intermittent sprocket
Ä Film pressure skate, here: 70 mm
Å Knob to open/close the lm
pressure skate
Æ Combined bottom / holdback sprocket
For smooth and silent lm running it is very important that the pressure of the lm
skate is adjusted accurately.
X
Z Adjusting the lm pressure skate, see chapter 6.4.
Z Changing lm gate parts, see chapter 3.2.8.
