Operation
Issue: 08/2012
Do not stand too close on rotating lm spools, because clothes, hair or other parts of
your body can get winded up or trapped into the spools.
• Switch on the external power supply for the performance room.
• Switch on the main switch
(position “I”).
$The switch illuminates red.
X
After 10 seconds the microprocessors are initialized, now the projector control takes up
the button commands.
• Thread the lm (see chapter 5.2) and do all adjustments either manually or automati-
cally by pushing the corresponding button.
• Push the button
.
$The projector is running, the ventilation is on, the xenon lamp is on.
• If necessary push the button
on projector’s operating panel, after the start leader
has run through.
X
Immediately after projector is switched on you must not manually turn the intermittent
sprocket (e. g. for lm threading) until the projector initialization is completed.
• Push the button
.
$The dowser closes, the xenon lamp gets off, the projector stops and the ventilation is
on (if temperature is more than 60° C).
• Switch off the main switch
(position “0”).
$The key lamp gets off.
• Switch off the external power supply for the performance room.
X
If you have an emergency stop, push the main switch
(position “0”), to cut the
power.
