Issue: 08/2012
Via pulses the main drive encoder counts quantity of lm (transport unit = 1 picture),
which is transported out of feed sprocket into lm gate.
If one “transport unit” is completely counted and shutter position is dark the motor of
intermittent sprocket carries on lm for one picture.
This operation is controlled by a microprocessor which is mounted on the main board.
X
Optimizing and Adjusting the intermittent sprocket drive should only be carried out by
service.
The friction is a shaft, which is driven with a constant turning moment from a motor.
Friction motor
Á Friction drive with toothed belt
 Friction shaft
X
Z Normally the set value is pre-adjusted and have not to change. If adjustments are
necessary, they should be carried out by Kinoton service only.
Z Operating the frictions, see chapter 4.3.
The reel shaft is mounted with a change-
able ange (for 35 mm or 70 mm lm).
To x a lm spool/reel you have either to
close lock bar or screw on a knurled nut.
• To change the ange loosen the 3 Allen
screws (arrows) and change the ange.
2
1
3
