Components
Issue: 08/2012
Frequency inverter
Á Relays (C/O, RUN, XENON)
 Fuse
à Mains lter
Ä Current at make limiter
Å Internal terminal strip
Æ Main fuse 6.3 AT
X
Adjusting the frequency inverter should
only be carried out by Kinoton service or
experts.
The frequency inverter (arrow) which con-
trols of the opposed rotating double shutter
is placed inside of the projector’s top.
X
Adjusting the frequency inverter should
only be carried out by Kinoton service
personnel.
2
4
6
5
1
3
7
