Issue: 08/2012
House light ON
Stage light ON
Focusing + (option)
House light HALF
Stage light STOP
Focusing - (option)
House light STOP
Stage light OFF
Frame UP
House light OFF
Frame DOWN
AUTO
START
Auto START
Projector START
Projector STOP
X
Z The standard auditorium panel I is equipped with a keyboard (4 x 4 buttons) and a
potentiometer to set the sound level.
Z The standard auditorium panel II is equipped with 2 keyboards (each 4 x 4 buttons)
and a potentiometer to set the sound level.
Z The RP4 auditorium panel is equipped with a keyboard (4 x 4 buttons) and the RP 4
remote panel for EMK 1 control.
