Issue: 08/2012
is printed as two wavy lines
on the lm.
The height of the amplitude signies loud-
ness, frequency signies pitch.
The information
(DOLBY SR·D) is encoded between the
perforations.
The information is en-
coded between the picture and the analog
sound track.
The information is encoded on the
edges of the lm.
The magnetic sound device reads the
magnetic track on the 70 mm lm.
X
Threading scheme, see chapter 5.2.
Optionally a DTS (see gure) or SDDS
reader can be used to scan the corre-
sponding sound track on the lm.
The readers will be fastened with special
holders on the projector.
