Technical Data
Issue: 08/2012
Name Cinema Projector
Type FP 75 E
Machine No. See data plate on housing.
Power supply 120 V / 230 V
Frequency 50 Hz / 60 Hz
Pre-fuse 10 A
Power max. 500 W (without xenon lamp)
Nominal rotary frequency of main
drive motor
1500 rpm
Power of main drive motor 100 VA
Framing Endless via remote control
Running speed 24/25 fps
10 - 30 fps VARIA (option)
Main fuse 6.3 AT
Fuse on main board 6.3 AT
Fuse on power supply unit 10 AT
Fuse on friction control board 3.15 AT
Projector 2266 mm x 750 mm x 424 mm approx. 210 kg
Film reels 600 m / 1800 m / 2000 m
Friction shafts Ø 12.7 mm
Lens holder for lenses Ø 70.6 mm and Ø 101.1 mm
Apertures (35 mm) 1:1.37 / 1:1.66 / 1:2.35
