Components
Issue: 08/2012
2
1
3
4
5
2
1
3
4
5
Combined sprocket / 35 mm sprocket
Á 70 mm pad shoe with handle / 35 mm pad shoe with handle
 Pad shoe chuck knob
à Film stripper
Ä IR lm break sensor
» The pad shoe holds the lm on the sprocket.
» On combined sprockets the pad shoe can be changed from 70 mm to 35 mm lm
format or vice versa.
» The lm stripper prevents broken lm from being wound up around the sprocket.
» With the handle you can open the pad shoe to thread the lm.
» The stop ball holds the open pad shoe in position, so you can easily thread the lm.
X
Z Changing a sprocket and/or pad shoe, see chapter 6.4.
Z Adjusting the distance between pad shoe and sprocket, see chapter 6.4.
Z Adjusting the lm break sensor, see chapter 6.4.
Z Changing the pad shoe for 35 mm or 70 mm lm, see chapter 3.2.8.
