Kobold VK200 - Taking out the Brush to Clean or Replace It

Maintenance93
4.3.2 TAKING OUT THE BRUSH TO CLEAN OR
REPLACE IT
REMOVING THE ROLLER BRUSH
1. Place the Automatic Electric Brush upside down.
2. Unlock the floor plate
by pressing the locks
on both sides at the same time with your
hands.
3. Take off the floor plate
.
4. First lift the green side of the roller brush out
of the Automatic Electric Brush and then pull the
black side
off the axle.
1
1
2
3
5
4
