Illustrated Parts List

SM7648-1 – 11NOV05 15

Figure 3 CP1 BOARD - MCU, TOP COVER AY, and TB1 BOARD - SHUTTER AND MODE DIAL

Item Part No. Description Quantity Notes

1 3F9178 SCREW - STPG, 1.7 x 3.5

3 2

2 3F9117 BOARD - TB1, shutter and mode dial

3 1

3 3F9181 SCREW - STPG, 1.7 x 4.5

3 1

4 3F9119 COVER - top

3 1

5 3F9166 FLEXIBLE CIRCUIT - CP1 to TB1

3 1

6 3F9184 SCREW - STPG, 1.7 x 4.5

3 2

7 3F9170 BUTTON - 5-way, joystick

3 1

8 3F6121 SCREW - PCS, 1.7 x 2.5

3 3

9 3F9168 BOARD - CP1, MCU

3 1

- - - - 3F9185 FUSE 5.0 A, 32 V

3 2See:

• “

CP1 BOARD - MCU, 1 of 2” on

Page 101

• “CP1 BOARD - MCU, 2 of 2” on

Page 102

- - - - 3F6051 FUSE 2.0 A, 32 V 3 3See “CP1 BOARD - MCU, 2 of 2” on

Page 102.
