Kodak EASYSHARE P850 Service Manual

SERVICE MANUAL
68 11NOV05 – SM7648-1
FRONT COVER AY
Prerequisites:
[1] Remove:
• BACK COVER AY
• MONITOR LCD AND VIEWFINDER AYs
To Remove:
[1] Remove:
• 4 SCREWS A
• 2 SCREWS B
• FRONT COVER AY
To Install:
[1] Reverse the steps in the removal procedure.
[2] Install:
• MONITOR LCD AND VIEWFINDER AYs
• BACK COVER AY
Postrequisites:
None
P264_1006GC
FRONT COVER AY
A
B
A
P264_1006GCA
