Additional Service Procedures
SM7648-1 – 11NOV05 77
Preparing the Test Equipment
Using the PATTERN BOX
[1] Energize the PATTERN BOX.
[2] Wait 30 minutes for the equipment to warm before using.
[3] Adjust:
• color temperature to 3100 +/- 20 K
• luminance to 900 +/- 20 cd/m
2
Using the CAMERA NEST
Distance
Placement of
CAMERA NEST
Color of STICKERS for
Placement of PINS Placement of TARGET
300 cm (118.1 in.) TRIPOD Green On the wall.
40 cm (15.7 in.) GEN II FIXTURE Yellow SLOT 4
114 cm (44.9 in.) GEN II FIXTURE Red SLOT 6
