Diagrams
SM7648-1 – 11NOV05 97
TB2 BOARD - FOCUS AND STROBE MODE
TB2
EVQPQHB55
1AV4S10B2591G
S6501
EVQPQHB55
1AV4S10B2591G
S6503
HN1D01FE
D6501
EVQP7J01K
S6502
4
5
6
1
2
3
SCAN OUT 4
SCAN OUT 5
SCAM IN 0
SCAN IN 1
FOCUS
LCD/EVF
CP1(SYA)CN303
FLASH
T2-02300/SX823-WKO
TB2 BOARD - FOCUS AND
STROBE MODE
2
64_0019EC_
